Convolute wheels: webrax-CWF (GWS)

Convolute wheels reinforced with foam for high stock removal (silicon carbide or aluminum oxide grain)
Product benefits
  • Very long service life with consistent high quality grinding results
  • Fine, repeatable surface finish
  • Machining of flat and complex shapes and contours
  • Can be used manually or automatically
  • Excellent price-performance ratio
/fileadmin/datapool/Unternehmensgruppe/Produktfinder/Produktbilder/640-99997.jpg
Applications
Metal working:
  • Deburring
    • Edge rounding
      • Fine finish
        Product design
        Type:
        webrax-CWF
        Grain:
        Aluminum oxide (A) / Silicon carbide (S)
        Bonding:
        Synthetic resin (partially free of components of animal origin)
        Backing:
        Nylon non-woven
        Grit range:
         Aluminum oxide (+ 80 (CRS) + 100 (MED) + 120 (MED) + 180 (FIN) + 280 (VFN)
        Silicon carbide (+ 80 (CRS) + 100 (MED) + 120 (MED) + 180 (FIN) + 280 (VFN) + 500 (SFN) + 800 (UFN))
        Stock programme Convolute wheels: webrax-CWF (GWS)

        For current delivery forms and times, please contact your local customer service or use our online service portal "Hermes Connect". Already registered as a customer there?

        Pictogram - material qualification steel very suitable
        Pictogram - material qualification stainless steel very suitable
        Pictogram - material qualification titanium very suitable
        Pictogram - material qualification high-alloy steel very suitable
        Pictogram - material qualification non-ferrous metal very suitable
        Pictogram - material qualification composite very suitable
        Very suitable
        Suitable

        Other dimensions and designs on request

        Download
        Product Data Sheet as a PDFProduct and application information on webrax® abrasivesVoluntary-Product-Information_G1.pdf
